IFP-75 Series Fire Alarm Control Panel

The IFP-75 Series Intelligent Fire Alarm Control Panels (FACPs) are advanced addressable fire alarm systems designed to provide reliable protection for commercial, industrial, and large-scale facilities. Featuring one SLC loop for IDP, SK, or SD devices, and dual technology communicators (IP and POTS), these panels ensure fast, precise fire detection and efficient notification management, while supporting networked systems up to 32 panels for extensive coverage.

Where It Can Be Used?

The is ideal for mid to large-sized buildings, including offices, hospitals, educational institutions, industrial plants, and multi-building campuses. Its networkable design allows it to monitor multiple floors or independent buildings, while the built-in communicators enable remote monitoring and reporting. It is particularly suited for installations where integration with remote annunciators, notification devices, and wireless gateways is required.

IFP-75 Series Fire Alarm Control Panel

The IFP-75 Series, including IFP-75, IFP-75B, IFP-75HV, and IFP-75HVB, is the next-generation replacement for the IFP-50 FACP. It supports up to 75 IDP/SK detectors and modules (150 points total) or 75 SD devices per loop. Two onboard Flexput® circuits provide programmable notification outputs or auxiliary power. Advanced features include drift compensation, pre-trouble maintenance alerts, calibration trouble alerts, and a built-in sensor test to meet NFPA 72 standards. With dual-line DACT communication (IP/POTS), optional cellular reporting, and networkability for up to 32 panels, the IFP-75 Series ensures a scalable, high-performance fire alarm solution.

Advantages

• Supports up to 150 points (IDP/SK) or 75 points (SD)
• Dual-line DACT with IP and optional cellular communication
• Two Flexput® circuits for NAC outputs or auxiliary power
• JumpStart® auto-programming reduces installation time
• 125 programmable software zones and output groups
• Selectable strobe synchronization for Amseco®, System Sensor, Wheelock®, Gentex® devices
• Built-in sensor test and maintenance alerts
• Networkable across up to 32 panels for large facilities
• Supports wired and wireless devices (SWIFT, IDP, SK, SD)
• Field-upgradeable firmware ensures long-term system reliability

Areas We Serve

Fire Projects Pvt Ltd. provides installation, commissioning, and maintenance of Honeywell IFP-75 Series panels across Gujarat, including Ahmedabad, Vadodara, Halol, Sanand, Vapi, Ankleshwar, and Dahej. We serve diverse sectors including commercial buildings, hospitals, educational campuses, industrial facilities, IT parks, and high-rise complexes.

Why Choose Fire Projects Pvt. Ltd.?

At Fire Projects Pvt. Ltd., we deliver complete fire safety solutions with certified Honeywell products. From system design and installation to ongoing support and maintenance, we ensure your fire alarm system is fully compliant, reliable, and future-ready. Our expert team provides tailored solutions for every facility size and complexity.

Contact us: +91 98244 42333 | Email: info@fireprojects.co.in
